How to Modify Ethereum Storage on Hardhat Mainnet Fork

Author: Konstantin Nekrasov
Security researcher at MixBytes

Modify Ethereum storage on Hardhat's mainnet fork

Set up a mainnet fork

How to modify a single slot variable

How to modify a mapping

How to modify an array

Сonclusion

Links

Hardhat has a cool feature to manually set the value of any storage slot with hardhat_setStorageAt. This feature is useful for whitehats to demonstrate a working exploit on Ethereum mainnet without causing real damage. The ability to fork mainnet is also useful for developers of integration tests: mocks may not take into account all the features of real contracts in the mainnet.

In this tutorial we'll set up a Hardhat mainnet fork and walk through several examples on how to find and modify storage variables in real contracts on the fork. We'll cover different types of variables including simple integers, packed values, mappings and arrays.

Set up a mainnet fork

First you need to have Hardhat installed. Check this tutorial on how to install Hardhat and create your first project:
https://hardhat.org/tutorial/setting-up-the-environment
In short you need to run:

mkdir modify-storage-tutorial
cd modify-storage-tutorial

npm init -y
npm install dotenv hardhat @nomiclabs/hardhat-ethers @nomiclabs/hardhat-waffle ethereum-waffle ethers chai

In simple mode Hardhat simulates a blockchain locally on your PC. In the fork mode it redirects your requests to a server with a snapshot of a real blockchain. Such an API, for example, is provided by alchemy.com and quicknode.com.

You can check their tutorials on how to fork Ethereum mainnet:
https://docs.alchemy.com/alchemy/guides/how-to-fork-ethereum-mainnet
https://www.quicknode.com/guides/web3-sdks/how-to-fork-ethereum-mainnet-with-hardhat
In this tutorial we'll work with Alchemy API. You must go to https://www.alchemyapi.io, sign up and create a new App in its dashboard. There you will get the API key needed to configure Hardhat. Put it in the .env file and don't forget to add the file name to .gitignore as this key is a secret:

echo 'ALCHEMY_API_KEY=XXXXXXXXXX' >> .env
echo '.env' >> .gitignore

Now create hardhat.config.js:

require("@nomiclabs/hardhat-waffle");

// read .env file
require('dotenv').config()

// Go to https://www.alchemyapi.io, sign up, create
// a new App in its dashboard, and export its key
// to the environment variable ALCHEMY_API_KEY
const ALCHEMY_API_KEY = process.env.ALCHEMY_API_KEY;

if (!ALCHEMY_API_KEY) throw new Error("ALCHEMY_API_KEY required");

/**
 * @type import('hardhat/config').HardhatUserConfig
 */
module.exports = {
  solidity: {
    compilers: [
      // you can add additional versions for your project
      {
        version: '0.8.9',
      },
    ],
  },
  defaultNetwork: "hardhat",
  networks: {
    hardhat: {
      forking: {
        url: "https://eth-mainnet.alchemyapi.io/v2/" + ALCHEMY_API_KEY,

        // specify a block to fork from
        // remove if you want to fork from the last block
        blockNumber: 14674245,
      }
    }
  }
};

Finally, you can check if everything works fine:

npx hardhat test

How to modify a single slot variable

Change Tether USD contract owner address

USDT smartcontract has a public variable address owner. Let's find its slot and change it to our signer address. Once this is done we'll be able to run some privileged methods like increasing the total supply.

First, we add an interface to communicate with USDT. The interface depends on IERC20 so we need to install Openzeppelin contracts:

npm install @openzeppelin/contracts

Now add a contracts/IUSDT.sol file:

import "@openzeppelin/contracts/token/ERC20/IERC20.sol";

interface IUSDT is IERC20 {
    function getOwner() external view returns (address);

    function issue(uint256) external;
}

The first guess is that the owner variable is at the zero slot. It appears to be true!

const { expect } = require("chai");
const { ethers } = require("hardhat");

const usdtAddress = "0xdac17f958d2ee523a2206206994597c13d831ec7"

// the slot must be a hex string stripped of leading zeros! no padding!
// https://ethereum.stackexchange.com/questions/129645/not-able-to-set-storage-slot-on-hardhat-network
const ownerSlot = "0x0"

it("Change USDT ownership", async function () {
    const usdt = await ethers.getContractAt("IUSDT", usdtAddress);
    const [signer] = await ethers.getSigners();
    const signerAddress = await signer.getAddress();

    // storage value must be a 32 bytes long padded with leading zeros hex string
    const value = ethers.utils.hexlify(ethers.utils.zeroPad(signerAddress, 32))

    await ethers.provider.send("hardhat_setStorageAt", [usdtAddress, ownerSlot, value])

    expect(await usdt.getOwner()).to.be.eq(signerAddress)
})

You can run the test to see that it passes:

npx hardhat test test/ChangeUSDTOwner.js

Mint USDT

Now that we're the owner we can mint additional tokens:

const { expect } = require("chai");
const { ethers } = require("hardhat");

const usdtAddress = "0xdac17f958d2ee523a2206206994597c13d831ec7"

// the slot must be a hex string stripped of leading zeros! no padding!
// https://ethereum.stackexchange.com/questions/129645/not-able-to-set-storage-slot-on-hardhat-network
const ownerSlot = "0x0"

it("Mint USDT", async function () {
    const usdt = await ethers.getContractAt("IUSDT", usdtAddress);
    const [signer] = await ethers.getSigners();
    const signerAddress = await signer.getAddress();

    // storage value must be a 32 bytes long padded with leading zeros hex string
    const value = ethers.utils.hexlify(ethers.utils.zeroPad(signerAddress, 32))

    await ethers.provider.send("hardhat_setStorageAt", [usdtAddress, ownerSlot, value])

    expect(await usdt.getOwner()).to.be.eq(signerAddress)

    const amount = 1000
    const before = await usdt.totalSupply()
    await usdt.issue(1000)
    const after = await usdt.totalSupply()

    expect(after - before).to.be.eq(amount)
})

Run the test to see that it passes:

npx hardhat test test/MintUSDT.js

How to modify a mapping

Change the USDC user balance

Now let's change a user balance in USDC smartcontract.

User balances are stored in the mapping(address => uint) balanceOf variable.

We can edit the balance directly via hardhat_setStorageAt but first we need to find the correct slot. It is a bit tricky. You can check how mappings are stored in Ethereum storage in https://docs.soliditylang.org/en/latest/internals/layout_in_storage.html#mappings-and-dynamic-arrays

Basically, the user balance is stored at the slot:

keccak256(padZeros(userAddress) . mappingSlot)

In javascript that is:

function getSlot(userAddress, mappingSlot) {
    return ethers.utils.solidityKeccak256(
        ["uint256", "uint256"],
        [userAddress, mappingSlot]
    )
}

So how do we know mappingSlot? Is this the slot of the balanceOf variable? We'll bruteforce it. You can read an example on how to do it in https://blog.euler.finance/brute-force-storage-layout-discovery-in-erc20-contracts-with-hardhat-7ff9342143ed

We'll bruteforce it with a simple check:

async function checkSlot(erc20, mappingSlot) {
    const contractAddress = erc20.address
    const userAddress = ethers.constants.AddressZero

    // the slot must be a hex string stripped of leading zeros! no padding!
    // https://ethereum.stackexchange.com/questions/129645/not-able-to-set-storage-slot-on-hardhat-network
    const balanceSlot = getSlot(userAddress, mappingSlot)

    // storage value must be a 32 bytes long padded with leading zeros hex string
    const value = 0xDEADBEEF
    const storageValue = ethers.utils.hexlify(ethers.utils.zeroPad(value, 32))

    await ethers.provider.send(
        "hardhat_setStorageAt",
        [
            contractAddress,
            balanceSlot,
            storageValue
        ]
    )
    return await erc20.balanceOf(userAddress) == value
}

And here is the bruteforce method:

async function findBalanceSlot(erc20) {
    const snapshot = await network.provider.send("evm_snapshot")
    for (let slotNumber = 0; slotNumber < 100; slotNumber++) {
        try {
            if (await checkSlot(erc20, slotNumber)) {
                await ethers.provider.send("evm_revert", [snapshot])
                return slotNumber
            }
        } catch { }
        await ethers.provider.send("evm_revert", [snapshot])
    }
}

The try..catch and evm_revert are needed because random storage modification may break the contract and cause an exception. Now we can write a final test to check that we can find and modify a user balance in USDC contract:

it("Change USDC user balance", async function() {
    const usdc = await ethers.getContractAt("IERC20", usdcAddress)
    const [signer] = await ethers.getSigners()
    const signerAddress = await signer.getAddress()

    // automatically find mapping slot
    const mappingSlot = await findBalanceSlot(usdc)
    console.log("Found USDC.balanceOf slot: ", mappingSlot)

    // calculate balanceOf[signerAddress] slot
    const signerBalanceSlot = getSlot(signerAddress, mappingSlot)

    // set it to the value
    const value = 123456789
    await ethers.provider.send(
        "hardhat_setStorageAt",
        [
            usdc.address,
            signerBalanceSlot,
            ethers.utils.hexlify(ethers.utils.zeroPad(value, 32))
        ]
    )

    // check that the user balance is equal to the expected value
    expect(await usdc.balanceOf(signerAddress)).to.be.eq(value)
})

Run the test to see that it passes:

npx hardhat test test/ChangeBalanceOf.js

How to modify an array

Modify Aave LendingPoolAddressesProviderRegistry

Let's analyze a simple example on how to find, read and modify a private dynamic address array in Aave's LendingPoolAddressesProviderRegistry which is stored at 0x52D306e36E3B6B02c153d0266ff0f85d18BCD413.

First we need to know how an address array is stored in Ethereum state:

Visibility modifiers such as private, public or internal do not affect the storage mechanism.
For an address dynamic array the slot p of the variable stores the number of elements. For example, if there are two elements in the array then the slot p stores 0x02.
The corresponding two elements are stored consequently starting from keccak256(p).
Even though the address type is 20 bytes long, each array element is still stored in a separate 32 byte slot. So, the first element of the array would be at slot keccak256(p) + 0 and the second element would be at keccak256(p) + 1.

If you are interested in how other types of arrays are stored, read https://docs.soliditylang.org/en/latest/internals/layout_in_storage.html#mappings-and-dynamic-arrays

The code of LendingPoolAddressesProviderRegistry is at https://github.com/aave/protocol-v2/blob/master/contracts/protocol/configuration/LendingPoolAddressesProviderRegistry.sol

We're interested in this part:

contract LendingPoolAddressesProviderRegistry is ... {
  mapping(address => uint256) private _addressesProviders;
  address[] private _addressesProvidersList;

  ...

  function getAddressesProvidersList()
    external
    view
    returns (address[] memory)
  { ... }

  function getAddressesProviderIdByAddress(
    address addressesProvider
  )
    external
    view
    returns (uint256)
  { ... }

  ...

We want to find the _addressesProvidersList slot. First, let's check its contents by calling the getAddressesProvidersList method. In order to do that we need to add an LendingPoolAddressesProviderRegistry interface to our project:

interface ILendingPoolAddressesProviderRegistry {
    function getAddressesProvidersList() external view returns (address[] memory);

    function getAddressesProviderIdByAddress(address addressesProvider) external view returns (uint256);
}

Now we can run it in Hardhat's console. Run the console with

npx hardhat console

Then run the javascript code:

const target = await ethers.getContractAt("ILendingPoolAddressesProviderRegistry", "0x52D306e36E3B6B02c153d0266ff0f85d18BCD413")

await target.getAddressesProvidersList()

Output:

[
  '0xB53C1a33016B2DC2fF3653530bfF1848a515c8c5',
  '0xAcc030EF66f9dFEAE9CbB0cd1B25654b82cFA8d5'
]

So, the array has two elements. Now we know that the slot of _addressesProvidersList stores the 0x02 value. Let's read the first few slots to find the value:

await ethers.provider.getStorageAt(target.address, "0x0")
await ethers.provider.getStorageAt(target.address, "0x1")
await ethers.provider.getStorageAt(target.address, "0x2")

Output:

0x000000000000000000000000b9062896ec3a615a4e4444df183f0531a77218ae
0x0000000000000000000000000000000000000000000000000000000000000000
0x0000000000000000000000000000000000000000000000000000000000000002

Let's analyze the storage layout:

slot 0 is used by some variable outside of our scope.
slot 1 seems to be used by mapping _addressesProviders since the mapping slot doesn't store elements and it is always zero.
slot 2 stores 0x02 and seems to be the slot for _addressesProvidersList?

Let't change slot 2 value to 0x03 so the array _addressesProvidersList would have 3 elements:

await ethers.provider.send(
  "hardhat_setStorageAt", [
    target.address,

    // the slot must be a hex string stripped of leading zeros! no padding!
    // https://ethereum.stackexchange.com/questions/129645/not-able-to-set-storage-slot-on-hardhat-network
    "0x2",

    // storage value must be a 32 bytes long padded with leading zeros hex string
    ethers.utils.hexlify(ethers.utils.zeroPad(3, 32))
  ]
)

Now let's call getAddressesProvidersList to see if that worked:

await target.getAddressesProvidersList()

Output:

[
  '0xB53C1a33016B2DC2fF3653530bfF1848a515c8c5',
  '0xAcc030EF66f9dFEAE9CbB0cd1B25654b82cFA8d5',
  '0x0000000000000000000000000000000000000000'
]

It worked! Now let's set the third element of the array to 0xDEADBEEF:

const arraySlot = ethers.BigNumber.from(ethers.utils.solidityKeccak256(["uint256"], [2]))
const elementSlot = arraySlot.add(2).toHexString()
const value = "0xDEADBEEF"
const value32 = ethers.utils.hexlify(ethers.utils.zeroPad(value, 32))

await ethers.provider.send(
  "hardhat_setStorageAt", [
    target.address,
    elementSlot,
    value32,
  ])

Now if we run getAddressesProvidersList again we will get:

[
  '0xB53C1a33016B2DC2fF3653530bfF1848a515c8c5',
  '0xAcc030EF66f9dFEAE9CbB0cd1B25654b82cFA8d5',
  '0x0000000000000000000000000000000000000000'
]

But why? Didn't we change the third element? The reason is in how getAddressesProvidersList works. It only outputs elements of the array if they are stored in mapping _addressesProviders. See the code at https://github.com/aave/protocol-v2/blob/master/contracts/protocol/configuration/LendingPoolAddressesProviderRegistry.sol#L33:

for (uint256 i = 0; i < maxLength; i++) {
  if (_addressesProviders[addressesProvidersList[i]] > 0) {
    activeProviders[i] = addressesProvidersList[i];
  }
}

return activeProviders;

Luckily we already know the slot of the _addressesProviders mapping: it is slot 1. We can directly add our 0xDEADBEEF to _addressesProviders:

const deadBeefSlot = ethers.utils.solidityKeccak256(
  ["uint256", "uint256"],
  [0xDEADBEEF, 1]
)
await ethers.provider.send(
  "hardhat_setStorageAt",
  [
    target.address,
    deadBeefSlot,
    ethers.utils.hexlify(ethers.utils.zeroPad(1, 32))
  ]
)

Let's check our array again:

await target.getAddressesProvidersList()

Output:

[
  '0xB53C1a33016B2DC2fF3653530bfF1848a515c8c5',
  '0xAcc030EF66f9dFEAE9CbB0cd1B25654b82cFA8d5',
  '0x00000000000000000000000000000000DeaDBeef'
]

Great! Value 0x00000000000000000000000000000000DeaDBeef is stored as the third element of the _addressesProvidersList array. You can run the full script as follows:

npx hardhat run scripts/ChangeAaveAddressProviderList.js

Сonclusion

In this article, we have analyzed several examples of how to find slots for different types of variables in Ethereum state, how to read and modify their values. We looked at how to modify public address, public mapping(address => uint) and private address[] in such contracts as USDT, USDC and Aave.

These tricks will definitely help you prepare and demonstrate working exploits. And if you're not a whitehat but a developer, then this will definitely help you write an integration test.

Good luck!

Links

Who is MixBytes?

MixBytes is a team of expert blockchain auditors and security researchers specializing in providing comprehensive smart contract audits and technical advisory services for EVM-compatible and Substrate-based projects. Join us on X to stay up-to-date with the latest industry trends and insights.

Disclaimer

The information contained in this Website is for educational and informational purposes only and shall not be understood or construed as financial or investment advice.
